General description Yuxiang® DDP is modified epoxy resin showed insulating coating on electrical baked DuPont™ Nomex® T410/Kraft paper/ Pet film/DMD/NMN/Aramid paper into a state of semi-curing insulation material. Typical Application With good bonding performance and reduction of partial discharge and Corona damage, Yuxiang® DDP can be used as oil-immersed power transformer coil turns of the wire insulation and insulation, also be used for Nomex® paper covered wire.

Backing Polyester film Backing Thickness mm 0.025±0.003 0.05±0.005 Adhesive Acrylic, Silicon Adhesive thickness mm 0.025/0.035±0.005 Total thickness mm 0.045/0.055±0.01 0.075/0.085±0.01 Heat resistant temperature Class B /130℃, Class C/200℃

General description Yuxiang® YHY/AHA is made of 3-layer flexible laminates comprised of 2 layers of Metastar®/X-Fiber® Aramid papers and a layer of polyimide film with thermal resistance adhesive. The total thickness of the product depends on the thickness of Aramid paper, also the properties. Typical Application Yuxiang® YHY/AHA is suitable for insulation in electrical motors and transformers with a maximum operating temperature of 180ºC. It is used in low or medium voltage rotating motors as ground and slot insulation. It can be used as well as intermediate layer in transformers. Typical Physical Properties Class H (180ºC) Good mechanical properties

Yuxiang® YX-5 electrical tape is based on Mylar A and high-performance electrician non-woven fabric and coated with modification of high temperature resistant acrylic adhesive. Yuxiang® YX-5 electrical tape has an excellent adhesion and mechanical properties, heat resistant level F (UL File #: E474901). The main application of bus bar insulation coating and fixed, at the same time, applied to the requirements for heat resistance is Scott motor and transformer coil end insulation and fixed, and so on.

YMY/AMA Good Equivalent of NMN Class H(180ºC) Good mechanical properties Aramid Paper made-in-China General description Yuxiang® YMY/AMA is a 3-ply flexible laminate made of Aramid paper - polyester film - Aramid paper, bonded with a synthetic adhesive. Application Yuxiang® YMY/AMA is suitable for insulation in electrical motors and transformers with a maximum operating temperature of 180ºC. It is used in low or medium voltage rotating machines as ground and slot insulation. It can be used as well as intermediate layer in transformers.

UL File #： E472622 General description Yuxiang® NMN is made of 3-layer flexible laminates comprised of 2 layers of Dupont Nomex® paper and a layer of polyester film with thermal resistance adhesive. The total thickness of the product depends on the thickness of Nomex® paper, also the properties. Meet the UL certification. Typical Application Yuxiang® NMN series is suitable for insulation in electrical motors and transformers with a maximum operating temperature of 155ºC~180ºC. It is used in low or medium voltage rotating machines as ground and slot insulation. It can be used as well as intermediate layer in transformers.

Be composed of DuPont Nomex® paper single-sided coating a layer of high temperature resistant acrylic pressure sensitive adhesive made from a kind of high temperature resistant insulating tape. Be mainly applied to the capacitor, reactor, transformer and motor coil winding and fixed. Has good solvent resistance and flame retardant properties.

▲Construction Backing: Polyester film reinforced with glass fiber Adhesive: Acrylic, thermosetting ▲Application 1.Ultra-high tensile strength tape with outstanding resistance to solvents and mineral oils for a variety of heavy duty applications 2.Engineered as a construction tape for easy winding of oil-filled distribution and power transformers 3.Binding motor and transformer coils and coil covering applications; lead and saddle tie down 4.Also used for concrete stenciling ▲Features & Benefits 1.Exceptional resistance to transformer oil and other chemicals, solvents and ageing when fully thermoset 2.High tensile and tear strength 3.High abrasion, puncture and edge-tear resistance 4.Conformable backing with aggressive adhesive 5.High dielectric strength and insulation resistance Total Tape Thickness 0.18mm /7 mils Backing Thickness 0.155 mm/6 mils Insulation Class Class F/155℃

▲General Description Yuxiang® YX-7 electrical tape is composed of polyimide film single-sided coating of high performance and the material of organic acrylic/silicon pressure-sensitive adhesive. They are resistant to high temperature insulation tape. ▲Typical Applications Yuxiang® YX-7 electrical tape is mainly used in higher requirement of H class motor and transformer coil insulation bandaging, a bandage fixed end of high-temperature resistance, temperature resistance measurement protection, capacitance and wire entanglement and other adhesive under the working conditions of high temperature insulation. Backing Polyimide Film Backing thickness (mm) 0.025 0.05 Total thickness (mm) 0.06±10% 0.08±10% Adhesive Acrylic/Silicon Temperature Class 180℃/220℃
