YHY/AHA
Yuxiang/Yohann
YHY
General description
Yuxiang® YHY/AHA is made of 3-layer flexible laminates comprised of 2 layers of Metastar®/X-Fiber® Aramid papers and a layer of polyimide film with thermal resistance adhesive. The total thickness of the product depends on the thickness of Aramid paper, also the properties.
Typical Application
Yuxiang® YHY/AHA is suitable for insulation in electrical motors and transformers with a maximum operating temperature of 180ºC. It is used in low or medium voltage rotating motors as ground and slot insulation. It can be used as well as intermediate layer in transformers.
Typical Physical Properties
Class H (180ºC)
Good mechanical properties
YHY/AHA | Aramid paper + PI film + Aramid paper | C | 0.07-0.5 | 3-1000 |
Yuxiang Flexible Laminates -
PRODUCTS | SUBSTRATE | TEMPERATURE CLASS | THICKNESS（mm） | WIDTH（mm） |
DMD | Dacron + PET film + Dacron | F | 0.08-0.5 | 3-1580 |
DM | Dacron + PET film | F | 0.06-0.5 | 3-1580 |
DMDMD | 5 layers of Dacron + PET film Composites | F | 0.3-3.0 | 10-1580 |
NMN | Nomex® paper + PET film + Nomex® paper | H, C | 0.1-1.4 | 3-1580 |
NM | Nomex® paper + PET film | F, H | 0.07-1.0 | 3-1580 |
NMNMN | 5 layers of Nomex® paper , PET film Composites | H | 0.9-1.4 | 10-1580 |
NHN | Nomex® paper + PI film + Nomex® paper | C | 0.1-0.5 | 3-904 |
NH | Nomex® paper + PI film | H | 0.07-0.94 | 3-904 |
YMY/AMA | Aramid paper + PET film + Aramid paper | H | 0.07-1.4 | 3-2000 |
YHY/AHA | Aramid paper + PI film + Aramid paper | C | 0.07-0.5 | 3-1000 |
SHS | Dacron + PI film + Dacron | H | 0.1-0.5 | 3-1030 |
SH | Dacron + PI film | H | 0.07-0.45 | 3-1030 |
YX130 | 3 layers of PET film Composites | B | 0.5-1.1 | 10-1580 |
TFT | Tufquin® paper + PET film + Tufquin® paper | H | 0.13-0.6 | 3-900 |
TF | Tufquin® paper + PET film | H | 0.08-0.48 | 3-900 |
